Front Loaded Glass Washers & Dishwashers_Germany Meiko
 Model:430F |
 Model:530F |
|
德国 Meiko
前置式洗杯机 Front Loaded Glass Washers |
德国 Meiko 前置式洗杯、洗碟机 Glass & Dishwashers |
|
技术参数：Technical data |
 型号：ECOSTA
430F |
型号：ECOSTA
530F |
||
| 总体尺寸 Dimensions (W x D x H) | 400 x 550 x 700 mm |
600 x 600 x 850mm |
||
| 洗涤篮规格 Basket dimensions | 400 x 400 mm |
500 x 500 mm |
||
| 洗涤能力 BasketCapacity | 30
Baskets/h |
30
Baskets/h |
||
| 水泵功率 Pump motor | 0.55 KW |
0.55 KW |
||
| 水槽容量 Tank filling | 11
L. |
20
L. |
||
| 漂洗用水量 Final rinse | 2.2L
/basket |
3L
/basket |
||
| 水槽加热器功率 Tank heating | 2
KW |
2
KW |
||
| 加热器功率 Boiler | 3
kW |
3
kW |
||
| 总功率 Total connected load | 3.5
kW |
3.55
kW |
||
标准配置 Standard features |
.230V,50赫兹 .120秒洗涤循环 .催干剂分配器 .自动清洗功能 .电漂洗加热器 |
.230V,50Hz .Pre-set 120secs .Rinse aid dosing .Self-cleaning unit .Electric booster |
.230V,50赫兹 .270秒洗涤循环 .催干剂分配器 .自动清洗功能 .电漂洗加热器 |
.230V,50Hz .Pre-set 270secs .Rinse aid dosing .Self-cleaning unit .Electric booster |
 |
前置式洗杯、洗碟机, 凝结了Meiko 70年的制造经验； | ||
| 70 years of dishwash manufacturing experience has led to the creation of these front-loaded dishwashers; | |||
 |
特点：Features | ||
| .上下嘴洗涤系统、双层内壁； | .Upper and lower wash systems,double-wall insulated; | ||
| .环保过滤系统、圆角深拉伸水槽； | .Enviroment-friendly filter system,deep-drawn tank with rounded corner; | ||
| .自动清洗功能、全电子轻触式控制面板； | .Self-cleaning cycle and electronic controls with sensor touch display; | ||
|
迈科产品以 省水、省电、省洗涤剂 而著称，专业人士选择Meiko; | ||
| .Meiko has developed a multitude of wash-up systems and solutions for the catering industry,which are ahead of competition in terms of saving the consumption of water,electricity,detergent and rinse-aid; | |||
